Underwater Non-Dispersible Grouting Material

High-performance grouting material specially designed for underwater construction, repair and reinforcement applications with excellent anti-dispersal and self-compacting properties.

15–40 MPa
Compressive (1d)
50–90 MPa
Compressive (28d)
β‰₯342 mm
Initial Flowability

Packaging & Delivery

Packaging3-ply paper-plastic composite bagSpec.25KG/bagVolume60*40*15cm
MOQ1000KGLead Time1-7 working daysShelf Life6 months (unopened, in dry conditions)
Trade TermsFOB/EXWPaymentT/T / L/CPortShanghai / Ningbo
Get a Quote
Underwater Non-Dispersible Grouting Material

Product Overview

Underwater Non-Dispersible Grouting Material is a specially formulated cement-based material developed for underwater repair and reinforcement. It features excellent anti-dispersal performance, high fluidity, self-compacting ability and rapid strength development, ensuring stable construction quality in underwater environments.

Product Features

Excellent Anti-Dispersal Performance
Does not easily disperse or wash out during underwater construction, maintaining material stability and ensuring underwater grouting quality.
Fast Strength Development
1d compressive strength 15-40MPa, 28d 50-90MPa, quickly meeting underwater structural load-bearing requirements.
Excellent Flowability
Initial flowability β‰₯342mm, 30min β‰₯338mm, suitable for pouring into complex underwater spaces.
Micro-Expansion Performance
3h vertical expansion rate 0.1%-3.5%, compensating for shrinkage and ensuring dense filling.
Self-Compacting Performance
Self-leveling without vibration, autonomously filling complex underwater gaps and voids.
Low Chloride Ion Content
Chloride ion content <0.1%, no corrosion risk to rebar, ensuring long-term durability of underwater structures.

Technical Specifications

ParameterValueTest StandardTest ResultStatus
Maximum Aggregate Size<4.75 mmGB/T 50448‑20154.20mm Pass
Initial FlowabilityClass II β‰₯342 mm / Class III β‰₯355 mm / Class IV β‰₯655 mmGB/T 50448‑2015Class II 356mm / Class III 368mm / Class IV 672mm Pass
30 min FlowabilityClass II β‰₯338 mm / Class III β‰₯350 mm / Class IV β‰₯555 mmGB/T 50448‑2015Class II 345mm / Class III 359mm / Class IV 580mm Pass
Vertical Expansion Rate (3h)0.1%–3.5%GB/T 50448‑20150.65% Pass
Compressive Strength (1d)15–40 MPa (depending on class)GB/T 50448‑201526MPa Pass
Compressive Strength (3d)30–70 MPa (depending on class)GB/T 50448‑201544MPa Pass
Compressive Strength (28d)50–90 MPa (depending on class)GB/T 50448‑201563MPa Pass
Chloride Ion Content<0.1%GB/T 50448‑20150.04% Pass
Water Bleeding Rate0GB/T 50448‑20150% Pass

Advantages

⚑

50% Higher Construction Efficiency

Self-compacting, freeze-thaw resistant, highly adaptable to environments. No vibration required, continuous pouring possible, reducing labor costs.

πŸ›‘οΈ

50% Shorter Construction Period

Early strength and high strength, non-shrink with micro-expansion, self-leveling. Compressive strength reaches over 25 MPa in 1 day and 42.5 MPa in 3 days. One-time pouring, simple operation.

πŸ’°

50% Lower Cost

Meets design specifications for key projects with guaranteed acceptance. Maintenance-free, reliable delivery, no worries, and long service life.

Applications & Operation Video

Trusted across diverse construction scenarios

1

Underwater Structure Repair

Used for reinforcement and repair of underwater concrete structures.

2

Underwater Pile Foundation Repair

Suitable for repairing defects and improving the performance of underwater piles.

3

Immersed Tunnel Sealing

Applied for sealing and reinforcement of immersed tunnel structures.

Click the play button to start the video

Usage Guidelines

β€’

Water-to-powder ratio: Follow manufacturer's specified mixing ratio

β€’

Working time: Use within 30 minutes after mixing

β€’

Underwater placement: Minimize water disturbance during grouting

β€’

Construction temperature: Ideally between 5℃~35℃

Storage & Shelf Life

Storage Condition

Store in a dry, ventilated place, protected from moisture.

Shelf Life

6 months (unopened, in dry conditions)

Successful Partnership Case Studies

Northwest Large-Scale Wind-Solar-Storage Integrated Wind Power Base Project

Category: Onshore Wind Turbine Foundation Grouting
Product: Wind Power High-Strength Grouting Material
Quantity: 5,500 tons
Location: Barkol, Xinjiang
Summary: Used for the connection between turbine foundations and tower bases.

East China High-Speed Railway Connection Line Project

Category: High-Speed Railway Bridge Bearing Reinforcement Grouting
Product: Bridge Bearing Special Grouting Material
Quantity: 4,000 tons
Location: Nanjing, Jiangsu
Summary: A key regional high-speed railway project, supplying bearing grouting materials.

Southern Pumped-Storage Power Station Foundation Treatment Project

Category: Hydropower Station Equipment Base Grouting Reinforcement
Product: Underwater Non-Dispersible Grouting Material
Quantity: 3,890 tons
Location: Qingyuan, Guangdong
Summary: A large domestic pumped-storage power station, supplying grouting for unit base equipment.

North China Heavy Industry Park Heavy Equipment Foundation Project

Category: Large Mechanical Equipment Secondary Grouting
Product: Early-Strength High-Strength Grouting Material
Quantity: 4,517 tons
Location: Dagang, Tianjin
Summary: A heavy equipment manufacturing park, supplying grouting for large unit equipment bases.
